Quick Details
- Type: Axial Flow Fan
- Electric Current Type: DC
- Mounting: Free Standing
- Blade Material: Plastic
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: HXH
- Model Number: HDB0305HG
- Voltage: 5V/12V/24V
- Power: 0.6-2.52W
- Air Volume: 2.60~5.07CFM
- Speed: 6000~12000RPM
- Certification: CE, ROHS, UL
- Poduct: dc brushless fan
- Bearing Type: Ball/Sleeve bearing
- Fan Dimension: 30X30X10mm
- Static Pressure: 1.17~3.87mmH2O
- Noise Level: 17.0~33.1dBA
- Color: Black
- Application: Projector,CPU Cooler
Packaging & Delivery
Packaging Details | 880pcs/carton |
---|---|
Delivery Time | Shipped in 15 days after payment |
HXH 30*30*10mm 5v 12v Computer Fan DC Brushless Cooling Fan 30mm DC Fan
Product Description

- 1. frame size(mm): 30X30X10
- 2. bearing system type: Ball bearing,Sleeve bearing
- 3. rated voltage: 5V/12V/24V
- 4. rated speed: 6000RPM 7500RPM 9000RPM 10500RPM 12000RPM
- 5. maxima air flow: 2.60CFM 3.18CFM 3.80CFM 4.33CFM 5.07CFM
- 6. maxima pressure: 1.17mmH2O 2.45mmH2O 2.90mmH2O 3.25mmH2O 3.87mmH2O
- 7. maxima noise: 17.0dBA 20.0dBA 24.8dBA 28.1dBA 33.1dBA
- 8. function: by impedance,by IC, by IC with FG
HXH 30*30*10mm series with different specifications for your choice:
30×30×10MM | ||||||||||||
Model | Bearing | Rated Voltage | Startup Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | |||
Part NO. | Function | System | VDC | VDC | A | W | RPM | M3/min | CFM | mmH2O | INH2O | dBA |
HDS0305HG | Sleeve | 5 | 4.0 | 0.30 | 1.50 | 9000 | 0.11 | 3.80 | 2.90 | 0.11 | 24.8 | |
HDS0305MG | 4.0 | 0.18 | 0.90 | 7500 | 0.09 | 3.18 | 2.45 | 0.10 | 20.0 | |||
HDS0305LG | 4.0 | 0.12 | 0.60 | 6000 | 0.07 | 2.60 | 1.17 | 0.05 | 17.0 | |||
HDB0305HG | Ball | 4.0 | 0.30 | 1.50 | 9000 | 0.11 | 3.80 | 2.90 | 0.11 | 24.8 | ||
HDB0305MG | 4.0 | 0.18 | 0.90 | 7500 | 0.09 | 3.18 | 2.45 | 0.10 | 20.0 | |||
HDB0305LG | 4.0 | 0.12 | 0.60 | 6000 | 0.07 | 2.60 | 1.17 | 0.05 | 17.0 | |||
HDS0312HG | Sleeve | 12 | 9.0 | 0.10 | 1.20 | 9000 | 0.11 | 3.80 | 2.90 | 0.11 | 24.8 | |
HDS0312MG | 9.0 | 0.08 | 0.96 | 7500 | 0.09 | 3.18 | 2.45 | 0.10 | 20.0 | |||
HDS0312LG | 9.0 | 0.06 | 0.72 | 6000 | 0.07 | 2.60 | 1.17 | 0.05 | 17.0 | |||
HDB0312EG | Ball | 9.0 | 0.21 | 2.52 | 12000 | 0.14 | 5.07 | 3.87 | 0.15 | 33.1 | ||
HDB0312UG | 9.0 | 0.13 | 1.56 | 10500 | 0.12 | 4.33 | 3.25 | 0.13 | 28.1 | |||
HDB0312HG | 9.0 | 0.10 | 1.20 | 9000 | 0.11 | 3.80 | 2.90 | 0.11 | 24.8 | |||
HDB0312MG | 9.0 | 0.08 | 0.96 | 7500 | 0.09 | 3.18 | 2.45 | 0.10 | 20.0 | |||
HDB0312LG | 9.0 | 0.06 | 0.72 | 6000 | 0.07 | 2.60 | 1.17 | 0.05 | 17.0 | |||
HDS0324HG | Sleeve | 24 | 12.0 | 0.07 | 1.68 | 9000 | 0.11 | 3.80 | 2.90 | 0.11 | 24.8 | |
HDS0324MG | 12.0 | 0.06 | 1.44 | 7500 | 0.09 | 3.18 | 2.45 | 0.10 | 20.0 | |||
HDS0324LG | 12.0 | 0.04 | 0.96 | 6000 | 0.07 | 2.60 | 1.17 | 0.05 | 17.0 | |||
HDB0324HG | Ball | 12.0 | 0.07 | 1.68 | 9000 | 0.11 | 3.80 | 2.90 | 0.11 | 24.8 | ||
HDB0324MG | 12.0 | 0.06 | 1.44 | 7500 | 0.09 | 3.18 | 2.45 | 0.10 | 20.0 | |||
HDB0324LG | 12.0 | 0.04 | 0.96 | 6000 | 0.07 | 2.60 | 1.17 | 0.05 | 17.0 |
Electric Strength | 5mA max at 1500VAC for 1 min between lead wire and frame |
Insulation Resistance | 10M ohm between lead wire and frame(DC 500V) |
Life Expectancy(Ball bearing) | 50000hrs min at 40 degree C/L10 relative humidity 65%+/-20% |
Life Expectancy(Hypro bearing) | >40000hrs min at 40 degree C/L10 relative humidity 65%+/-20% |
Life Expectancy(Fluid Dynamic bearing) | >60000hrs min at 40 degree C/L10 relative humidity 65%+/-20% |
Operation Temperature | -10~75 degree C(+14~167 degree F),normal; -10~90 degree C(+14~194 degree F), specification |
Storage Temperature | Storage Temperature: -40~75 degree C(-40~167 degree F) |
Protection | Motor protection and polarity protection |
Lead wire | UL1571 AWG28,30; UL1007 AWG24,26; UL1061 AWG26 |
Plastic Material | Black PBT(UL94V-0) |
Applications
1.Home appliance 2.Kitchen 3.Car industry 4.Telecom 5.Medical Equipment 6. UPS Power7. LED Lighting 8.Computer 9.Safety Equipment 10.Office Electrics
Packaging & Shipping
1. 880pcs/carton.
2. 15 days after confirm your order and receive your payment
3. We ship goods to worldwide! Product will be ship by EMS, FedEx, DHL, or UPS.
4. Please check with your local agency as you might be required to pay custom duty/tax on import of this goods, all custom duty/tax pay by buyer. We HXH do not responsible for any custom duty or import tax.
5. All items will be packed safely by our professional logistic department, please check the product before Signoff, if your item is damaged or lost by Express, please Reject. Meanwhile, please contact us immediately so we can assist with correcting the problem A.S.A.P, And we will report to the Express and ask for refund.
2. 15 days after confirm your order and receive your payment
3. We ship goods to worldwide! Product will be ship by EMS, FedEx, DHL, or UPS.
4. Please check with your local agency as you might be required to pay custom duty/tax on import of this goods, all custom duty/tax pay by buyer. We HXH do not responsible for any custom duty or import tax.
5. All items will be packed safely by our professional logistic department, please check the product before Signoff, if your item is damaged or lost by Express, please Reject. Meanwhile, please contact us immediately so we can assist with correcting the problem A.S.A.P, And we will report to the Express and ask for refund.
Company Information








- 2012,7:Factory expansion again, Set up the radiator module division, passed UL certification.
- 2011.5:Factory expanded, moved to Dongguan and found Dongguan Hesen Industrial Co.,Ltd.
- 2007.4:Factory passed ISO9001 quality system certificate. CE certificate passed, manufacture all series of AC and DC FAN.
- 2004.5:Build Shenzhen Haixinghe Electronic Co., Ltd, creat our own brand "HXH".
- 2001.8:processing plant was given priority to with OEM, manufacture part of the model fan for part of the customers.
